30% Glass Fiber Reinforced Polyether Ether Ketone (PEEK GF30)

What is 30% Glass Fiber Reinforced Polyether Ether Ketone (PEEK GF30)?

30% Glass Fiber Reinforced Polyether Ether Ketone combines the benefits of PEEK with the added strength of glass fiber, creating a stronger thermoplastic polymer. This combination enhances PEEK's mechanical strength and structural stability. Available in both metric and imperial sizes for any project.

Key Properties

PEEK GF30 has improved tensile strength compared with unfilled PEEK, ranging from 150 to 170 MPa. Further evidence of this material's strength is demonstrated by its high modulus of elasticity, ranging from 3,000 to 4,000 MPa (435,000 to 580,000 psi). Choose PEEK GF30 over unfilled PEEK when high strength and stiffness are critical.

30% Glass Fiber Reinforced Polyether Ether Ketone (PEEK GF30) Datasheet

Download Here

Industries Benefiting from PEEK GF30

  • Automotive

    In the automotive industry, PEEK GF30 is used for applications that require excellent strength, stiffness, and dimensional stability at elevated temperatures. Its resistance to fuels, oils, chemicals, and wear makes it particularly suitable for demanding under-the-hood, transmission, electrical, and powertrain applications. Its lightweight nature and strength make it ideal in this industry.

  • Industrial Engineering

    Industrial engineering requires components that can withstand chemicals and high temperatures whilst maintaining stiffness, strength, creep resistance, and dimensional stability. PEEK GF30 possesses these characteristics, making it a strong choice for various industrial engineering applications.

  • Electrical & Electronics

    PEEK GF30 can withstand heat and mechanical loads whilst maintaining its tolerances and electrical insulation. Within the electrical and electronics industry, PEEK GF30 is suited to demanding applications such as connectors, sockets, switches, coil formers, and insulating components.

  • Oil & Gas

    Components used in the oil and gas industry are exposed to high temperatures, mechanical loads, and aggressive chemicals. PEEK GF30 provides a solution to these aggressive operating conditions, with its increased stiffness and excellent resiostance to hydrocarbons, fuels and many other processing chemicals. It is ideal for use in valve components, seals and support components, and electrcial insulators.
